Self Lubricating Bronze Bushings Steel Slide Plate Code Number SCLSP 20mm

Large Image : Self Lubricating Bronze Bushings Steel Slide Plate Code Number SCLSP 20mm Get Best Price

Product Details:

Place of Origin:	CHINA
Brand Name:	INWAY
Certification:	ISO9001
Model Number:	TSP

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	Negotiation
Packaging Details:	Carton+pallet
Delivery Time:	5 work days or based on quantity
Payment Terms:	T/T,L/C
Supply Ability:	100 tons/month

Contact Now

Detailed Product Description

Material:	S45C Steel	Thickness:	20mm
Screw:	2 Holes Or 4 Holes	Feature:	OEM Production,Long Life,oil Free
Lubrication:	Oil Free,Oil-free Self-lubricated	Standard:	JIS
Highlight:	self lubricating bronze bushings , self lube bushings , Self Lubricating Bronze Bushings

Self Lubricating Bronze Bushings Steel Slide Plate SCLSP 20mm

Steel slide plate Code number SCLSP 20mm Self Lubricating Bearings according to Sankyo oilless specifications.

Product Features

Superior performance under high load and low rotating speed conditions
Centrifuge cast high intensity brass base with solid-lubricant-inlaid design
Excellent friction resistance and self-lubrication properties
Prevents scoring and seizure even under harsh operating conditions
Maintains superior properties in high-load, low-speed applications

Product Operation

High performance in high-load and low-speed operations
Apply small amount of grease for initial lubrication during die spotting
Ideal for reciprocating motions, oscillation, and frequent start-stop cycles

Product Application

Sliding surface develops black or black-gray film from special solid lubricant during operation (normal condition - do not remove)
Superior wear resistance in applications where oil film is seldom present
Serviceable without requiring additional lubrication

Wear Plate Specifications

Base Metal	Oilless Type	Thickness	Code No.	Features
FC250	Graphite	20	SESF	Excellent sliding performance at low load and medium speed
FC250	Graphite	20	SESFT	Excellent sliding performance at low load and medium speed
SS400	Copper Powder sintering	20	SOX	Excellent sliding performance at low/medium load and medium speed. Limited seizure occurrence with sintered copper-based powder and graphite layer
SS400	Copper Powder sintering	20	SOXT	Excellent sliding performance at low/medium load and medium speed. Limited seizure occurrence with sintered copper-based powder and graphite layer
S45C		10	TWX
S45C		10	TWXT
Copper alloy	Graphite	20	SESW	Excellent load resistance and wear resistance. Excellent sliding performance at high load and low speed. Good performance in reciprocating and frequent start-stop applications
Copper alloy	Graphite	20	SESWT	Excellent load resistance and wear resistance. Excellent sliding performance at high load and low speed. Good performance in reciprocating and frequent start-stop applications
Copper alloy	Graphite	10	TWP	Excellent load resistance and wear resistance. Excellent sliding performance at high load and low speed. Good performance in reciprocating and frequent start-stop applications
Copper alloy	Graphite	10	TWPT	Excellent load resistance and wear resistance. Excellent sliding performance at high load and low speed. Good performance in reciprocating and frequent start-stop applications
Copper alloy	Graphite	5	UWP	Excellent load resistance and wear resistance. Excellent sliding performance at high load and low speed. Good performance in reciprocating and frequent start-stop applications
Steel (S45C)	Graphite	20	FRP	Surface hardness HRC40 or more, excellent wear resistance
Steel (SKS3)	Graphite	20	TSP	Surface hardness HRC58 or more, greatly excellent wear resistance
