Oilless Self Lubricating Bearings Deep Groove Structure With Superior
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Steel | Thickness: | 20 Mm |
|---|---|---|---|
| Feature: | OEM Production,Long Life,oil Free | Lubrication: | Oil Free,Oil-free Self-lubricated |
| Standard: | PSA | Structure: | Deep Groove |
| Highlight: | Oilless Self Lubricating Bronze Bushings,Deep Groove Self Lube Bushings,Deep Groove Self Lubricating Bearings |
||
Oilless Self Lubricating Bearings Deep Groove Structure With Superior Performance
Oilless self-lubricating bearings with deep groove structure deliver superior performance in demanding industrial applications where traditional lubrication methods are impractical or undesirable.
Product Features
- Eliminates the need for frequent oil maintenance, reducing environmental contamination and lowering operational costs
- Maintains excellent wear resistance even in challenging conditions with reciprocating, rocking movements, and frequent start-stop cycles
- Features superior chemical and corrosion resistance with solid lubricants made from special graphite and PTFE for stable molecular structures
Product Operation
- Available in various standard sizes to meet diverse application requirements
- Superior chemical resistance and corrosion resistance properties
- Operates effectively without requiring external lubrication
Product Application
- Delivers high performance under high-load and low-speed operating conditions
- Self-lubricating bearings with embedded solid lubricant and metal base conforming to ASTM Standards (C86300)
- Functions reliably without the need for lubrication maintenance
Wear Plates Specifications
| Base Metal | Oilless Type | Material | Thickness | Code No. | Features |
|---|---|---|---|---|---|
| FC250 | Graphite | 20 | SESF | Excellent sliding performance at low load and medium speed | |
| 20 | SESFT | Excellent sliding performance at low load and medium speed | |||
| SS400 | Copper Powder sintering | 20 | SOX | Excellent sliding performance at low/medium load and medium speed. With the sintered layer using copper based powder and graphite, occurrence of seizure is very limited | |
| 20 | SOXT | Excellent sliding performance at low/medium load and medium speed. With the sintered layer using copper based powder and graphite, occurrence of seizure is very limited | |||
| S45C | - | 10 | TWX | - | |
| 10 | TWXT | - | |||
| Copper alloy | Graphite | 20 | SESW | Excellent in load resistance and wear resistance. Good performance is shown in reciprocating and frequent starts and stops | |
| 20 | SESWT | Excellent in load resistance and wear resistance. Good performance is shown in reciprocating and frequent starts and stops | |||
| 10 | TWP | Excellent sliding performance at high load and low speed | |||
| 10 | TWPT | Excellent sliding performance at high load and low speed | |||
| 5 | UWP | Excellent sliding performance at high load and low speed | |||
| Steel (S45C) | Graphite | 20 | FRP | Since the surface hardness is HRC40 or more, it is excellent in wear resistance | |
| Steel (SKS3) | - | 20 | TSP | Since the surface hardness is HRC58 or more, it is greatly excellent in wear resistance |
