Block Bronze Wear Plate INW V guide type BP Sliding with Solid Lubricant
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Shape: | V Block | Application: | Cam Unit |
|---|---|---|---|
| Size: | Customized | Standard: | INW |
| Type: | Cutting Tools | Processing Type: | Machined Parts |
| Highlight: | brass wear plate,self lubricating bushing material |
||
Block Bronze Wear Plate INW V Guide Type BP with Solid Lubricant
INW V Guide VDI3357 Bronze wear plate with solid lubricant for cam unit applications.
Manufactured from bronze with solid lubricant for oilless lubrication operation.
Product Features
- High performance with excellent stress resistance and smooth sliding operation
- Eliminates the need for oil lubrication systems in design planning
- Maintains self-lubricating function even under high load conditions
Product Operation
- Available in various standard sizes for multiple applications
- Superior chemical resistance and corrosion resistance properties
- Operates effectively without requiring additional lubrication
Product Application
- Delivers high performance in high-load and low-speed operating conditions
- Self-lubricating bearing with embedded solid lubricant in metal base
- Conforms to universally-acknowledged ASTM Standards (C86300)
- Maintenance-free operation without lubrication requirements
Technical Specifications
| Screw holes | ℓ1 | ℓ2 | ℓ3 | t1 | t2 | d1 | d2 | d3 | d4 | VDI Code | Catalog No. | L | T | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Type W 2 |
─ | 125 | 100 | 47 | 20 | 13.5 | 20 | 12 | 14 | VDI3357－G－751 | BP | 65 | 150 | 44 |
| ─ | 175 | 150 | VDI3357－G－752 | 200 | ||||||||||
| 3 | 125 | 225 | 200 | VDI3357－G－753 | 250 | |||||||||
| 150 | 275 | 250 | VDI3357－G－754 | 300 | ||||||||||
