JIS Standard Sintered Metal Bearings DNB #2000 20mm Thickness For Tyer Mould

Large Image : JIS Standard Sintered Metal Bearings DNB #2000 20mm Thickness For Tyer Mould Get Best Price

Product Details:

Place of Origin:	CHINA
Brand Name:	INWAY
Certification:	ISO9001
Model Number:	VDI3357

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	Negotiation
Packaging Details:	Carton+pallet
Delivery Time:	5 work days or based on quantity
Payment Terms:	L/C, T/T
Supply Ability:	100 tons/month

Contact Now

Detailed Product Description

Material:	Steel Sintered With Layer	Thickness:	20mm
Application:	Tyer Mould	Size:	Customized
Standard:	VDI3357	Holes:	2 Or 4 Screw Holes
Highlight:	Tyre Mould Sintered Bronze Bearing , 20mm Self Lube Wear Plates , JIS Standard Sintered Metal Bearings

JIS Standard Sintered Metal Bearings DNB #2000 20mm Thickness For Tire Mould

The DNB-#200P20 20mm thick wear plate is a copper-based component that combines the wear resistance of a metal substrate with the self-lubricating properties of solid lubricant. This product requires no refueling or maintenance during operation and is extensively used for high-load, intermittent, or oscillating applications in tire moulds, reservoir work/emergency gates, and plastic machinery.

Product Features

Self-lubricating design eliminates maintenance requirements
Excellent wear resistance for demanding applications
Copper-based construction with solid lubricant integration
Ideal for high-load and oscillating operations
JIS standard compliant manufacturing

Technical Parameters (Unit: mm)

Please select the part number according to required thickness, width, and length. For example, ordering code DNB-#200P20-2875 indicates 20mm thickness, 28mm width, and 75mm length.

Parts No.	Width	Length	Thickness	Mounting Holes Pitch	Number of Screw Holes	Chamfered Shape
#200P20-2875	28	75	20	45	2	C
#200P20-28100	28	100	20	50	2	C
#200P20-28150	28	150	20	100	2	C
#200P20-3875	38	75	20	45	2	C
#200P20-38100	38	100	20	50	2	C
#200P20-38150	38	150	20	100	2	C
#200P20-4875	48	75	20	45	2	B
#200P20-48100	48	100	20	50	2	B
#200P20-48125	48	125	20	100	2	B
#200P20-48150	48	150	20	100	2	B
#200P20-48200	48	200	20	100	2	B
#200P20-48250	48	250	20	45	3	B
#200P205875	58	75	20	50	2	C
#200P20-58100	58	100	20	75	2	C
#200P20-58150	58	150	20	100	2	C
#200P20-7575B	75	75	20	25	2	A
#200P20-75100B	75	100	20	50	2	A
#200P20-75125	75	125	20	75	2	A
#200P20-75150	75	150	20	100	2	A
#200P20-75200	75	200	20	150	2	A
#200P20-75250	75	250	20	100	3	A
#200P20-75300	75	300	20	100	3	A
#200P20-100100	100	100	20	50	4	C
#200P20-100125	100	125	20	50	4	C
#200P20-100150	100	150	20	50	4	C
#200P20-100200	100	200	20	50	4	C
#200P20-100250	100	250	20	50	4	C
#200P20-100300	100	300	20	50	4	C
#200P20-125125	125	125	20	50	4	C
#200P20-125150	125	150	20	50	4	C
#200P20-125200	125	200	20	50	4	C
#200P20-125250	125	250	20	50	4	C
#200P20-125300	125	300	20	50	4	C
#200P20-150150	150	150	20	100	4	C
#200P20-150200	150	200	20	100	4	C
#200P20-150250	150	250	20	100	4	C

As one of the leading China sinter DNB#200 P20 manufacturers and suppliers, DERNORE provides sinter DNB#200 P20 distribution. Welcome to wholesale products from our factory.
