Sankyo SOX SOXT Sintered Metal Bearings With Dispersed Solid Lubricant
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Steel Sintered With Layer | Lubricating: | Lubricated |
|---|---|---|---|
| Application: | Tyer Mould | Size: | Customized |
| Structure: | Metal To Metal | Standard: | JIS |
| Highlight: | Tyre Mould Sintered Bronze Bush,Dispersed Solid Lubricant Sintered Bronze Bearing,Solid Lubricant Sintered Metal Bearings |
||
Sankyo SOX SOXT Sintered Metal Bearings With Dispersed Solid Lubricant
Oiles 2000 Sintered multi-layer bearings with dispersed solid lubricant
Key Features
- Dispersed solid lubricant allows motions in any direction and offers superior performance for minute movements
- Serviceable without the need for lubrication
- Features superior load resistance, speed characteristics, and wear resistance
- Standard products and plates for additional machining are available in various sizes
Bearings with Superior Wear Resistance for Multi-Directional Use
The Oiles 2000 series are composite multi-layer bearings composed of sliding surfaces made of special sintered material and steel back metals. Solid lubricant mainly made of graphite is dispersed in the sintered layer, which is sintered and impregnated with oil.
Technical Specifications
| Service Range | Dry | Periodic Lubrication |
|---|---|---|
| Service Temperature Range (°C) | -40 to +120 | -40 to +120 |
| Allowable Max. Contact Pressure: P (N/mm²) | 24.5 | 49 |
| Allowable Max. Velocity: V (m/s) | 0.50 | 1.00 |
| Allowable Max. PV Value (N/mm²・m/s) | 1.63 | 2.45 |
Powder Metallurgy Manufacturing Process
- First, the metal (bronze or bronze alloy) is made into powdered form through methods including grinding, chemical decomposition, or atomization
- The metallic powder is poured into a die or mold cavity and compacted under great pressure at room temperature to adhere the particles
- The metal part is inserted into a furnace where extreme heat fuses the metal particles together to form a rigid, high-strength porous component (sintering)
The resulting porosity of the sintered parts makes powder metal products especially useful in lubricating applications. Bearings and wear plates are often fabricated from sintered bronze, offering both strength and flexibility. Additionally, they provide a cost-effective production process that includes oil impregnation or permanent lubrication.
