FRP Self Lubricating Bearings According Sankyo Oilless Steel Slide Plate Code Number
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | S45C Steel | Thickness: | 20mm |
|---|---|---|---|
| Screw: | 2 Holes Or 4 Holes | Feature: | OEM Production,Long Life,oil Free |
| Lubrication: | Oil Free,Oil-free Self-lubricated | Standard: | JIS |
| Highlight: | self lubricating polymer,self lubricating bronze bushings,FRP Self Lubricating Bearings |
||
FRP Self Lubricating Bearings According Sankyo Oilless Steel Slide Plate Code Number
Steel slide plate Code number FRP Self Lubricating Bearings according Sankyo oilless
Product Features
- Traditional mechanical designs require frequent oil maintenance and regular checks of oil levels and delivery systems, which can cause machine and environmental contamination while increasing maintenance costs
- Superior performance delivers lower operational costs - self-lubricating bearings maintain clean surroundings while eliminating lubricant expenses
- Excellent performance under high load and low rotating speed conditions - solid-lubricant-inlaid bushings use high-intensity brass created through centrifugal casting for optimal load-bearing capability
Product Operation
- Demonstrates high performance under high-load and low-speed operations
- Apply minimal grease for initial lubrication during die spotting
- Ideal for reciprocating motions, oscillation, and frequent start-stop applications
Product Application
- High-performance operation under high-load and low-speed conditions
- Self-lubricating bearing with embedded solid lubricant and metal base conforming to ASTM Standards (C86300)
- Serviceable without requiring additional lubrication
Types of Wear Plates
| Base Metal | Oilless Type | Material | Thickness | Code No. | Features |
|---|---|---|---|---|---|
| FC250 | Graphite | 20 | SESF | Excellent sliding performance at low load and medium speed | |
| 20 | SESFT | Excellent sliding performance at low load and medium speed | |||
| SS400 | Copper Powder sintering | 20 | SOX | Excellent sliding performance at low/medium load and medium speed. With the sintered layer using copper based powder and graphite, occurrence of seizure is very limited | |
| 20 | SOXT | Excellent sliding performance at low/medium load and medium speed. With the sintered layer using copper based powder and graphite, occurrence of seizure is very limited | |||
| S45C | 10 | TWX | |||
| 10 | TWXT | ||||
| Copper alloy | Graphite | 20 | SESW | Excellent in load resistance and wear resistance. Good performance is shown in reciprocating and frequent starts and stops | |
| 20 | SESWT | Excellent in load resistance and wear resistance. Good performance is shown in reciprocating and frequent starts and stops | |||
| 10 | TWP | Excellent in load resistance and wear resistance. Good performance is shown in reciprocating and frequent starts and stops | |||
| 10 | TWPT | Excellent in load resistance and wear resistance. Good performance is shown in reciprocating and frequent starts and stops | |||
| 5 | UWP | Excellent in load resistance and wear resistance. Good performance is shown in reciprocating and frequent starts and stops | |||
| Steel (S45C) | Graphite | 20 | FRP | Since the surface hardness is HRC40 or more, it is excellent in wear resistance | |
| Steel (SKS3) | 20 | TSP | Since the surface hardness is HRC58 or more, it is greatly excellent in wear resistance |
