Casting Iron SESF SESFT Oil Free Bushing 2 Holes 4 Holes Follow Sankyo
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Casting Iron With Graphite | Thickness: | 20mm |
|---|---|---|---|
| Screw: | 2 Holes Or 4 Holes | Feature: | OEM Production,Long Life,oil Free |
| Lubrication: | Oil Free,Oil-free Self-lubricated | Standard: | JIS |
| Highlight: | Casting Iron self lubricating bronze bushings,4 Holes Oil Free Bushing,2 Holes Oil Free Bushing |
||
Casting Iron SESF SESFT Oil Free Bushing 2 Holes 4 Holes Follow Sankyo
Casting Iron SESF SESFT Oil Free Bushing 2 Holes 4 Holes Follow Sankyo
Product Features
- Operate without lubrication - eliminates need for lubricating systems, reduces assembly time, prevents oil pollution, maintains clean environment, and lowers costs
- Utilizes special graphite with excellent self-lubricating properties to create self-lubricating bushings with comprehensive advantages
- Available in various standard part sizes to accommodate customer design standards
Product Operation
- Delivers high performance under high-load and low-speed operating conditions
- Apply minimal grease for initial lubrication during die spotting
- Suitable for various motion types including reciprocating motions, oscillation, and frequent starts and stops
Product Application
- Excellent performance in high-load and low-speed operating environments
- Self-lubricating bearing with embedded solid lubricant and metal base conforming to ASTM Standards (C86300)
- Operates effectively without requiring additional lubrication
Wear Plate Specifications
| Base Metal | Oilless Type | Material | Thickness | Code No. | Features |
|---|---|---|---|---|---|
| FC250 | Graphite | 20 | SESF | Excellent sliding performance at low load and medium speed | |
| 20 | SESFT | ||||
| SS400 | Copper Powder sintering | 20 | SOX | Excellent sliding performance at low/medium load and medium speed. With the sintered layer using copper based powder and graphite, occurrence of seizure is very limited | |
| 20 | SOXT | ||||
| S45C | 10 | TWX | |||
| 10 | TWXT | ||||
| Copper alloy | Graphite | 20 | SESW | Excellent in load resistance and wear resistance. Excellent sliding performance at high load and low speed. Good performance is shown in reciprocating and frequent starts and stops | |
| 20 | SESWT | ||||
| 10 | TWP | ||||
| 10 | TWPT | ||||
| 5 | UWP | ||||
| Steel (S45C) | Graphite | 20 | FRP | Since the surface hardness is HRC40 or more, it is excellent in wear resistance | |
| Steel (SKS3) | 20 | TSP | Since the surface hardness is HRC58 or more, it is greatly excellent in wear resistance |
