Bronze Cast Bronze Bushings CuZn37Mn3Al2PbSi Cross Oil Groove JIS Standard
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Automobile Application | Size: | Standard |
|---|---|---|---|
| Standard: | JIS | Oil Groove: | Cross Oil Groove |
| Material: | CuZn37Mn3Al2PbSi | Type: | Straight |
| Highlight: | cast bronze sleeve bearings,small brass bushings |
||
Bronze Cast Bronze Bushings CuZn37Mn3Al2PbSi Cross Oil Groove JIS Standard
Material Specifications
CuZn37Mn3Al2PbSi Bronze Alloy
Standards: EN 12164, EN 12165, EN 12167
- Connecting Rods Applications
- Industrial Applications
Typical Industrial Applications
Bushings, Shafts, Cams, Chain Guides, Wear Plates, Gears, Food Conveyor Chain, Connecting Rods
Available Dimensions
 |
Round: 10mm - 80mm |
|
Hexagonal: 10mm - 55mm |
|
Square: 10mm - 40mm |
|
Rectangle: W: 10mm - 102mm |
|
Bar Length: 3000mm |
|
Profile: According to customer drawing |
Cylindrical Bushes Material: CW713R
Chemical Composition (% max, unless shown as range or min)
| Cu | Al | Fe | Mn | Ni | Pb | Si | Sn | Zn | Others Total |
|---|---|---|---|---|---|---|---|---|---|
| 57.0 - 59.0 | 1.3 - 2.3 | 1.0 | 1.5 - 3.0 | 1.0 | 0.2 - 0.8 | 0.3 - 1.3 | 0.4 | Rem | 0.3 |
Applicable Specifications
BS EN 12164, BS EN 12165, BS EN 12167
Fabrication Processes
- Hot Forging and Pressing
- Machining
INW-62 Casting Alloy Bronze applied with new and improved copper alloys manufactured in our own foundry is what we see to be one of the key foundations of our company's success story. We cooperate closely with institutes of universities, research institutes and customers to tailor the performance of our products to the application requirements.
Additional Product Types
- Flanged bushes
- Thrust washers
- Sliding plates
We accept requests for detailed datasheets with comprehensive information about material characteristics and design specifications.
