VSOL Self Lube Wear Plates Cam Slide Guide INW L Sankyo Cam Slide Guide INW Standard
Product Overview
The VSOL Self Lube Wear Plates are high-performance cam slide guides featuring bronze construction with integrated solid lubricant for oilless operation. These angled guide gib components provide reliable performance in industrial applications requiring precision sliding motion.
Key Features
- Bronze construction with solid lubricant for maintenance-free operation
- Oilless lubricating system eliminates the need for external lubrication
- Precision ground sliding faces for smooth, accurate movement
- Graphite impregnated brass bushings for enhanced durability
- Wide operating temperature range from -40°C to 150°C
Technical Specifications
| Type | Straight |
|---|---|
| Bushing Material | Graphite Impregnated Brass |
| I.D. d (mm) | 6 |
| O.D. D (mm) | 10 |
| Maximum Allowable PV Value (N/mm²•m/s) | 1.65 |
| Maximum Allowable Load (N/mm²) | 29 |
| Operating Temperature Range (°C) | -40 to 150 |
| Operating Temperature Range (No Lubrication) Min | -40 |
Dimensions Catalog
| Catalog No. | W | L | W1 | W2 | L1 | L2 | L3 | T | t | d | d1 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| VSOL-01 | 25 | 125 | 18 | 9 | 15.5 | 8.5 | 9 | 6 | |||
| VSOL-02 | 160 | ||||||||||
| VSOL-03 | 125 | ||||||||||
| VSOL-04 | 32 | 160 | 22 | 11 | 27.5 | 10 | 30.5 | 15.5 | 11 | 8 | |
| VSOL-05 | 200 | ||||||||||
| VSOL-06 | 55 | 100 | 37 | 20 | o | 55.5 | 39.5 | 13.5 | 10 | ||
| VSOL-07 | 160 | ||||||||||
| VSOL-11 | 160 | ||||||||||
| VSOL-12 | 70 | 200 | 50 | 30 | 35 | 12.5 | 75.5 | 55.5 | 17.5 | 12 | |
| VSOL-13 | 250 | ||||||||||
| VSOL-15 | 400 | 125 | |||||||||
| VSOL-16 | 160 | ||||||||||
| VSOL-17 | 85 | 200 | 63 | 38 | 42.5 | 15 | o | 90.5 | 65.5 | 22 | 16 |
| VSOL-18 | 250 | ||||||||||
| VSOL-20 | 400 | 125 |
