Guide Bushes SEFW Solid Lubricant Bearings Sleeve Universal Flange Type
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Features: | Low Resistance,Long Operating Life,Maintenance,High Precision | Material: | Bronze |
|---|---|---|---|
| Type: | Sleeve | Size: | Standard Size,Customizable |
| Product Name: | Brass Bush,Sleeve Bearing | Lubricating: | Oilless |
| Highlight: | Flange Type Solid Lube Bearings,Universal Bronze Bushing Lubrication,Flange Type Solid Lubricant Bearings |
||
Guide Bushes SEFW Solid Lubricant Bearings Sleeve Universal Flange Type
SEFW guide bushings, flange type, SO#50SP2 bronze with graphites, consist of highly wear-resistant copper cast alloy with sliding surfaces evenly embedded with solid lubricant plugs. The high-strength copper alloy provides exceptional load-bearing capacity while the solid lubricant forms a low-friction film during operation.
Under technical dry running conditions, the bearing surface features a thick running-in film that transfers solid lubricant to the counter material upon initial contact.
High-Strength Brass Bearings with Embedded Solid Lubricant
Optimal Design and Wide Application
The lubricant arrangement in solid-lubricant-inlaid bushings ensures all friction set components receive lubrication during operation. Lubricant placement is determined by the operating direction of corresponding friction sets.
Superior Chemical and Corrosion Resistance
The lubricant in solid-lubricant-inlaid bushings is made from special graphite and PTFE with stable molecular structures. The metal base can be selected according to specific chemical and corrosion resistance requirements, providing superior performance in demanding environments.
Key Features
- Serviceable without the need for external lubrication
- Suitable for reciprocating motions, oscillation, frequent starts and stops
- Superior chemical resistance and corrosion resistance
- Standard products available in various sizes
Application Notes
- Use standard designation when designing whenever possible
- Ensure surfaces are free of foreign matter during assembly
- Do not remove the black or grey film on sliding surfaces - this is the protective oil film formed by solid lubricant during use
