VDI SP2 Sankyo VDI 3357 VW AUDI Standard Self Lubricating Bearings Copper Alloy Graphite Pluged
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Bronze With Graphite | Thickness: | 20mm |
|---|---|---|---|
| Lubrication: | Oil Free,Oil-free Self-lubricated | Standard: | European |
| Type: | Long Type | Precision Rating: | High |
| Highlight: | self lubricating polymer,self lube bushings,20mm Self Lubricating Bearings |
||
VDI SP2 Sankyo VDI 3357 VW AUDI Standard Self Lubricating Bearings Copper Alloy Graphite Pluged
VDI 3357 slider plate 2960.93 VDI SP2 Self Lubricating Bearings copper alloy graphite plugged
VDI3357 Standard Sliding Pad
Material: Bronze with solid lubricant, oilless lubricating
Execution: Sliding faces ground
Material: Bronze with solid lubricant, oilless lubricating
Execution: Sliding faces ground
| Type | Straight | Bushing Material | Graphite Impregnated Brass |
|---|---|---|---|
| I.D. d(mm) | 6 | O.D. D(mm) | 10 |
| Maximum Allowable PV Value(N/mm²•m/s) | 1.65 | Maximum Allowable Load(N/mm²) | 29 |
| Operating Temperature Range(℃) | -40~150 | Operating Temperature Range (No Lubrication) Min | -40 |
Product Features
- Utilizes special graphite with excellent self-lubricating properties to create bearings that combine all advantages of self-lubrication
- Operates without oil and provides self-lubrication due to the linear coefficient expansion of solid lubricant being greater than that of the metal base
- During operation, the oil film transfers to corresponding friction surfaces to enable effective self-lubrication
Product Operation
- Demonstrates high performance under high-load and low-speed operations
- Apply a small amount of grease for initial lubrication in die spotting
- Ideal for reciprocating motions, oscillation, frequent starts and stops, and similar applications
Product Application
- Excellent performance in high-load and low-speed operating conditions
- Self-lubricating bearing with embedded solid lubricant and metal base conforming to universally-acknowledged ASTM Standards (C86300)
- Serviceable without the need for lubrication
