SNW0102 Self Lubricating Bushing Material , Oil Free Bushing Steel Material Type
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Steel With Graphite | Thickness: | 20mm |
|---|---|---|---|
| Feature: | OEM Production,Long Life,oil Free | Lubrication: | Oil Free,Oil-free Self-lubricated |
| Standard: | NAAMS | Type: | Sliding,plate |
| Highlight: | self lubricating bronze bushings,self lube bushings,Oil Free Self Lubricating Bushing |
||
SNW0102 Self Lubricating Bushing Material, Oil Free Bushing Steel Material Type
SNW0102 Self Lubricating Bushing Material, Oil Free Bushing Steel Material Type
Product Features
- Eliminates the need for frequent oiling and maintenance checks required by traditional mechanical designs, reducing environmental contamination and maintenance costs
- Superior performance delivers lower operational costs while maintaining clean operating environments
- Maintains excellent performance characteristics even under high load and low rotating speed conditions
Product Operation
- Superior wear resistance in applications where oil film formation is limited
- Operates effectively without requiring lubrication
- Ideal for reciprocating motions, oscillation, and frequent start-stop applications
Product Application
- High performance under high-load and low-speed operating conditions
- Self-lubricating bearing with embedded solid lubricant and metal base conforming to ASTM Standards (C86300)
- Serviceable without lubrication requirements
Sliding Characteristics (Lubricating Condition: No Lubrication)
| Wear Plate | Hardened Surface with HRC25 or More | Heat Treated Steel or FC Casting Less than HRC25 | Raw Material (SS400) | ||||||
|---|---|---|---|---|---|---|---|---|---|
| P (N/mm²) | V (m/min) | PV Value | P (N/mm²) | V (m/min) | PV Value | P (N/mm²) | V (m/min) | PV Value | |
| FC Type | 5 | 10 | 30 | 5 | 10 | 30 | 5 | 10 | 30 |
| Sintered Type | 50 | 30 | 100 | 25 | 30 | 60 | 25 | 30 | 50 |
| Bronze Type | 100 | 15 | 150 | 50 | 15 | 150 | 25 | 15 | 150 |
