INW-TS-70C Nail Plate Composite Slideway Water Conservancy Project Bearings
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Engine Bearing | Size: | Standard |
|---|---|---|---|
| Standard: | DIN1494 | Material: | Steel+CuSn6Ni9 |
| Type: | X Type | Technical: | Wrapped Bronze |
| Highlight: | bimetal bushing,bimetal bearing bushes |
||
INW-TS-70C Nail Plate Composite Slideway Water Conservancy Project Bearings
The INW-TS-70C Nail Plate Composite Slideway Bearings are engineered specifically for water conservancy projects, offering superior performance and durability in demanding hydraulic applications.
Technical Specifications
| Parameter | TS-70A | TS-70C |
|---|---|---|
| Alloy Material | ZQAL9-4 | ZQAL9-4 |
| Hardness | ≥110HB | ≥110HB |
| Tensile Strength | ≥390MPa | ≥390MPa |
| Plastics | Reinforcing PTFE | Oil nylon plastic alloy |
| Rail Radius (mm) | 150-300 | 150-300 |
| Allowable Load (KN/mm) | 3-5 | 4-7 |
| Friction Coefficient (Aging) | μ∞≤0.1 | μ∞≤0.1 |
| Static Friction (Water) | μo 0.075 | μo 0.080 |
| Dynamic Friction (min) | μd 0.055 | μd 0.055 |
| Allowable Wear Capacity (mm) | 2.5 | 2.5 |
| Allowable Wear Stroke (m) | 2500 | 4000 |
| In Force Wear Stroke (mm) | 4 | 4 |
Standard Dimensions
Total Thickness: 20±0.1 mm
Length: 2500-0.5, 3000-0.5, 3500-0.5, 4000-0.5, 5000-0.5 mm
Width: 120±0.3, 160±0.3 mm
NSP Nonstandard Parts: Available according to original processing requirements
Length: 2500-0.5, 3000-0.5, 3500-0.5, 4000-0.5, 5000-0.5 mm
Width: 120±0.3, 160±0.3 mm
NSP Nonstandard Parts: Available according to original processing requirements
Appearance: Copper alloy without cracks, allowing minimal plastic porosity
Performance Characteristics
TY Standard Parameters
| Parameter | Value |
|---|---|
| Steel Hardness | ≥45 HRC |
| Copper Hardness | ≥80 HB |
| Max. Load Static | 50 N/mm² |
| Max. Load Dynamic | 30 N/mm² |
| Max. Speed | 2 m/s |
| Max. PV | 1.8 N/mm²*m/s |
| Friction Coefficient | 0.03-0.20 |
| Temperature Range | -50℃ to +250℃ |
Key Features
- Steel-backed bronze alloy lined bearing material
- Optional oil groove work surface for improved lubrication
- Lower friction compared to traditional steel bushes
- Excellent wear resistance and high temperature tolerance
- Proven success in high-speed mold & die industries
Advanced Technical Parameters
| Parameter | Value |
|---|---|
| Max. Load Static | 250 N/mm² |
| Max. Load Dynamic | 100 N/mm² |
| Max. Speed (Dry) | 0.5 m/s |
| Max. Speed (Oil) | 1.0 m/s |
| Max. PV | 3.25 N/mm² * m/s |
| Hardness | HB > 210 |
| Temperature Range | -100℃ to +300℃ |
| Friction Coefficient | 0.03-0.20 |
| Thermal Conductivity | 60 W/(m*K) |
| Coefficient of Thermal Expansion | 19 × 10⁻⁶ K⁻¹ |
| Yield Point | 150 N/mm² |
Contact Details
Zhejiang In-way Precision Machinery Co., Ltd
Contact Person: james
Send your inquiry directly to us
